| Diesel Engine Water pump | ||
| Water pump | Pump model | DP20 |
| Suction. Discharge Port dia.(mm) | 50（2〞） | |
| Cont Capacity(m³/h) | 36 | |
| Cont Head(m) | 26 | |
| Max Sucking(m) | 8 | |
| Self-Priming Time(s/4m) | 80 | |
| Engine | Engine Model | SE170F |
| Rated Power(hp) | 4 | |
| Bore × Stroke(mm) | 70×55 | |
| Fuel Consumption(g/kw/h) | ＜284 | |
| Starting System | Recoil Starter or E-Starter | |
| Rated Speed(rpm) | 3000 | |
| Displacement(cc) | 212 | |
| Fuel Type | (summer)0#, (winter)10# | |
| Fuel Tank Capacity(L) | 2.5 | |
| Oil Capacity(L) | 0.75 | |
| Dimension & Packing | Net Weight(kg) | 35 |
| Dimension(L*W*H)(mm) | 475*400*515 | |
| Packing | In Strong Corrugated Board Carton | |
| 20FT Loading Quantity | 180 | |
| 40HQ Loading Quantity | 360 | |
| Payment | Payment Terms | T/T or L/C |
| Minimum Order Quantity | 5 PCS | |
| Delivery Lead Time | Within 15days after received the depsoite | |
| Warranty | One Year or 500 Working Hours | |
